Product Description
We engineer our compact transformer station to deliver robust voltage step-down and power distribution capabilities in environments where land space is at a premium. Having served major heavy industrial groups and national power grids for over two decades, we have refined this compact transformer station to offer the highest power density per square meter. The unit's enclosure is fabricated from high-strength, double-layer insulated panels that provide excellent thermal barriers and noise dampening. Choosing our compact transformer station ensures a highly cost-effective, durable, and safe distribution node for any medium-voltage commercial or industrial grid.
Our intelligent factory is fully equipped with advanced CNC bending machines, laser cutters, and automated welding lines to ensure that every compact transformer station meets precise structural tolerances. Our dedicated R&D department, which includes senior electrical engineers, continuously innovates to improve safety features, including internal arc protection, automated fire suppression interfaces, and mechanical interlocking mechanisms. We operate under rigorous green-manufacturing and ISO system standards, guaranteeing that each compact transformer station we deliver is highly efficient, has minimal environmental impact, and is built to last for decades of continuous service.
Specifications
|
Incoming Maximum Voltage |
35 kV / 40.5 kV |
|
Outgoing Rated Voltage |
0.4 kV / 0.69 kV |
|
Maximum Rating |
up to 2500 kVA |
|
Rated Short-circuit Breaking Current |
25 kA / 31.5 kA |
|
Noise Level |
≤ 45 dB (at 1 meter distance) |
|
Housing Protection Level |
IP54 / IP55 |
Application Areas
- High-Speed Railway Power Lines & Suburban Grids
- Mining & Heavy Industrial Complexes (e.g., Cement and Steel Mills)
- Temporary Large-scale Exhibition Zones & Events
- Municipal Infrastructure & Drinking Water Treatment Facilities
Customization Capabilities
Our OEM/ODM services are designed to match your exact technical blueprints. We can configure the compact transformer station with specific dry-type or oil-immersed transformers, customize the low-voltage outgoing circuits, and adjust the physical entry/exit points for high-voltage and low-voltage cables to match your pre-existing on-site concrete pads.
Packaging & Shipping
Every unit is secured with high-tensile steel tie-downs to heavy shipping skids. It is then shrink-wrapped with UV-resistant film and fitted with corner impact protection. We offer comprehensive logistics management under EXW, FOB, and DDP shipping terms to handle all customs clearance and transport challenges on your behalf.
FAQ
Q: What is the delivery time for a standard compact transformer station?
A: Our delivery cycle for standard-configured models is approximately 10 days, allowing you to meet tight project deadlines and fast-track grid installations.
Q: How do you handle product quality control?
A: We control quality through an intensive three-level protocol: self-inspection by operators, mutual inspection between workshops, and specialized final testing by our QA engineers.
